From Continental to Deep-sea setting on the Atlantic Margin

Outcrop exposures from the westernmost side of the Basque Trough display more- or-less in continuity the transition from shelf to basinal environments. This transition forms a fault-controlled shelf-break setting, with several secondary faults still well-preserved on the main footwall in the landward direction, and a series of normal faults along the palaeo-slope. In addition, a Triassic salt diapir influenced deep-water sedimentation at the platform margin, creating localized depocenters for turbiditic and other gravitational deposits. A series of erosional unconformities formed as a consequence of the salt movement.

The outcrops are depicting the development of two main types of sand-rich deposits in relationship with the structuration:

  • shallow-water sandstones with high N/G ratio directly filling small-scale tilted fault blocks onto the main footwall,
  • a complex suite of deep-water gravitational deposits developing in the hangingwall on the seaward side of the margin.

 The objective of this field course in the Basque Country is to analyse:

  • the change in stratal pattern and facies from continental to deep-marine deposits along the basin margin, in relationship with the structural development of the Basque- Cantabrian domain. The outcropping successions are both time-equivalent and facies-equivalent to Norwegian Sea basin margin successions at the transition between the Nordland Ridge-Froya High and Donna/Halten Terrace zones.
  • the salt influence on both slope and deep-sea sedimentation


Deep-water Paleocene-Eocene fan system

from the Atlantic margin


The coastal exposures of the southern margin of the Bay of Biscay, Basque Country in both France and Spain, provide the opportunity to study the facies, the architecture and the sequence stratigraphy of a deep marine succession ranging in age from Albian to Early Eocene.

Facies types are ranging from fine-grained basin-plain deposits to coarse-grained channelized debris flow.  All the turbidite facies types are visible within their stratigraphic context in continuity from bottom upward.  The turbidite deposits can be well compared to those found on the Norwegian margin.  They are deposited as localized chaotic debris in an immature basin physiography during the Early Cretaceous as a consequence of the opening of the Bay of Biscay.  They became well organized forming a major deep-sea fan system during the Late Cretaceous, when the basin deepened as a consequence of the thermal passive margin subsidence.  They formed a major prograding slope fan complex during the Early Eocene, recording the onset of the Pyrenean compression.

The primary objective of the field trip is to provide a methodology for analyzing and predicting the architecture and the reservoir stacking pattern of a fan system in both unconfined and confined deep-marine environment.  The sequence stratigraphic framework of the turbidite deposits is set up, allowing to demonstrate the diachroneity of each individual sand package along dip and strike.  Large-scale comparisons are made with sub-surface sections from the North Sea and Vøring Basins.
